Seaward PrimeTest 100 PAT Tester


The PrimeTest 100 is a highly useful and functional handheld PAT tester!

The simple 3 button operation facilitates quick and accurate PAT testing at the touch of the button.

It is an easy-to-use, comprehensive manual PAT tester for testing earth continuity, insulation resistance and substitute leakage with measured test result values.

A battery-powered, handheld PAT tester that is suitable for low volume testing.  The screen displays both measured test result values and pass/fail indicators.  In addition, the tester can display a number of error/advice messages to assist the user when running the tests.  The Primetest 100 has the capability of basic data logging and label printing when used in conjunction with the Seaward PATMobile app.

By simply pushing its button the PrimeTest 100 will give you three operational modes: Class I and II, IEC Lead test mode or Power Socket mode.  It’s the ideal choice for those looking for an easy-to-use, electrical safety tester.

Connect the PrimeTest 100 to a power outlet and it will automatically check the socket wiring and mains voltage.  Users are able to ensure the mains supply has been correctly wired.

It features a large LCD digital display to show your test result values, as well as a PASS or FAIL indication.  Being battery operated it’s lightweight helping you work quicker and more efficiently.

Our Lead Trainer says –
The displaying of the test measurements allows the user to make an informed decision on pass/fail – especially useful when testing extension leads.  The addition of a substitute leakage test is a useful feature.  A very popular choice of tester.

Easy information management

Unlock extra features with Seaward‘s free and easy-to-use mobile app, PATMobile.  Available for use on both Android and iOS devices, the handy app works with the PrimeTest 100 enabling the digital input and storage of test records alongside barcode scanning, label printing* and photo tagging.

Where other testers struggle

The unique design of the PrimeTest 100 incorporates Seaward’s High/Low current test techniques which ensure accurate and repeatable measurement where other testers struggle to provide reliable readings.

The PrimeTest 100 is used by 1,000‘s of people to test millions of appliances every day.

Key Features:

  • Simple-to-use push button operation
  • Easy-to-read display with LCD display – shows test results and pass/fail indication
  • Accurate and reliable earth continuity testing
  • Handheld and battery powered
  • Long battery life
  • Compatible with free PATMobile app – enables you to log results, export your data, tag photos and print results*

Electrical/Analysis Test Functions:

  • Mains supply check
  • IEC lead test
  • Earth continuity (200mA)
  • Insulation resistance (500V)
  • Alternative/substitute leakage

Ideal for:

  • Low volume testing
  • Manually recorded measurements

Please note: the PrimeTest 100 does not have a backlight. *Print label feature only available for Android devices.
