Kewtech KEW3127 5KV Insulation Tester

Regular price £1,895.00 £0.00

KEW3127 5KV (HIGH CURRENT) INSULATION TESTER

PRODUCT INFORMATION

KEY BENEFITS

  • Insulation Resistance up to 10TΩ
  • Short-Circuit Current up to 5mA
  • Wide Test Voltage from 250V to 5000V
  • Diagnostic Insulation Tests: IR, PI, DAR, DD, SV, RAMP (Breakdown and Burn modes), Capacitance, Leakage Current

KEY FEATURES

  • Wireless communication byBluetooth for transferring and showing real-time data to PC and Android device
  • Memory and Logging functions
  • Filter function reduces noise interference for obtaining stable measurements
  • Large back light display with Bar-Graph indication
  • Robust design for field use with IP65 (lid closed)
  • Powered by rechargeable battery
  • Safety Standard IEC61010-1 CAT.IV 600V

INCLUDES

  • 7165A (Line probe)
  • 7224A (Earth cord)
  • 7225A (Guard cord)
  • 8019 (Hook type prod)
  • 8254 (Straight type prod)
  • 8327EU (Power adaptor 15V/1A)
  • 9171 (Hard case)
  • Instruction manual
  • Calibration Certificate

 WEIGHTS & DIMMENSIONS

  • Weight KEW3127: 4kg Approx. (including battery)
  • Weight Total: 8kg Approx. (including accessories)
  • Dimmensions KEW3127: 208(L) x 225(W) x 130(D) mm
  • Dimmensions Hard Case: 380(L) x 430(W) x 154(D) mm
