Fluke 718Ex


Fluke 718Ex Intrinsically Safe Pressure Calibrator

Available in 30G, 100G, and 300G Pressure Ratings


Potentially explosive atmospheres can be found in a variety of manufacturing environments from chemical or pharmaceutical processing, to oil refineries—or any environment where flammable material (gas or dust/particulates) are present. Fluke’s intrinsically safe test tools can be used to help you perform maintenance and calibration tasks in potentially explosive and hazardous classified areas. Fluke offers the widest range of reliable, accurate and intrinsically safe test tools. Including true-rms multimeters, infrared thermometers, process calibrators, pressure calibrators, loop calibrators and precision pressure test gauges.

The Fluke 718EX 300 Intrinsically Safe Pressure Calibrator measures pressure via a 1/8-Inch NPT pressure fitting and an internal pressure sensor or via Fluke 700PEX Series Pressure Modules. The calibrator simultaneously displays pressure and current measurements, performs switch testing and measures current up to 24 mA.

The calibrator's unit button selects a different pressure unit. All units are available when the pressure sensor input is used. The damp button turns pressure reading damping on and off. With damping on, the calibrator averages several measurements before displaying a reading. The Calibrator automatically turns off after 30 minutes of inactivity.

This equipment is specified for use in measurement category I (CAT I) pollution Degree 2 environments and should not be used in CAT II, CAT III, or CAT IV environments.-voltage transients should not exceed 300-volts for the CAT I applications where this product is used. Do not use in a damp or wet environment.


Fluke 718Ex Comes Supplied With:

  • Holster
  • 9-volt Alkaline Battery
  • Set of TL75 Test Leads
  • Set of AC72 Alligator Clips
  • Control Drawing and CD-Rom


Key Features:

  • ATEX II  1G Ex ia IIC T4 Compliant.
  • Built-in pressure / vacuum hand pump, with fine adjust vernier and bleed valve.
  • 30, 100, and 300 psi ranges (2, 7, and 20 bar)
  • Pressure measurement to 0.05% of full span, using an internal pressure sensor.
  • Pressure measurement to 200 bar using any of eight intrinsically safe Fluke 700PEx Pressure Modules.
  • Wide range of selectable measurement units for pressure.
  • Current measurement with 0.02% accuracy and 0.001 mA resolution.
  • Pressure switch test function.
  • Min-Max Hold functions.
  • Compact size and weight.
  • Simple, push-button user interface.
  • Rugged and reliable, ideal for field use.


 Fluke 718Ex is Available in the Folowing Formats:

718 Ex 30G -12 PSI to 30 PSI (-82.7 kPa to 207kPa) 0.001 PSI (0.01 kPa) 0.05% FS
718 Ex 100G -12 PSI to 100 PSI (-82.7 kPa to 690 kPa) 0.01 PSI (0.01 kPa) 0.05% FS
718 Ex 300G -12 PSI to 300 PSI (-82.7 kPa to 2068 kPa) 0.01 PSI (0.01 kPa) 0.05% FS


About Intrinsically Safe Products

Products that appear on this website that are listed as or relate to a classification of intrinsic safety are titled and described according to our best understanding and/or interpretation of the complex and sometimes changing criteria governing such classification as set out by the Health and Safety Executive.

Please note that due to the volatile nature of the intended use of products in this category,  neither UK Test Instruments or Instrument Sales and Service can be held responsible for any incident that arises from the purchase or use of any product described within this web site. For more information please visit the health and Safety Executive website with specific regard to Hazardous Area Classification and Control of Ignition Sources.
